The Elecrow Pico W5 is a powerful microcontroller development board built around the Raspberry Pi RP2040 chip, tailored for IoT and embedded applications. Featuring a 32-bit dual-core ARM Cortex-M0+ processor running at up to 133 MHz, it offers reliable performance for various tasks. This upgraded version surpasses the original Pico W with enhanced features such as dual-band WiFi (2.4 GHz/5 GHz), Bluetooth 5.0, a larger flash memory, and a USB Type-C interface.
Its form factor remains consistent with the Raspberry Pi Pico, ensuring compatibility with most Pico accessories and modules. Supporting both MicroPython and C/C++, it provides developers with flexibility and ease of use. The board also includes user-friendly features like a reset and boot button, user LED, and a stamp hole design for seamless integration into custom boards. Ideal for IoT, edge computing, STEM education, and rapid prototyping, the Pico W5 is a low-cost, high-performance solution for modern embedded systems.
Features:
RP2040 Chip—Dual-core ARM Cortex-M0+ processor, up to 133 MHz.
Dual-Band WiFi—Supports 802.11a/b/g/n at 2.4 GHz and 5 GHz.
Bluetooth 5.0—Low-power BLE support for modern wireless applications.
Larger Flash Storage—More onboard flash than the original Pico W.
Type-C Interface—Easier and more robust USB connection.
Compatible Form Factor—Same size and pinout as Raspberry Pi Pico.
Multi-Language Support—Develop with MicroPython and C/C++.
Developer-Friendly—Includes boot/reset buttons, LED indicator, SDK, and open-source tutorials.
Item Type: | Development Board |
|---|
RAM Capacity: | 264 KB |
|---|
Processor Type: | 32-bit Arm Cortex |
|---|
CPU | 32-bit ARM |
|---|
Interface: | Type-C |
|---|
Operating Temperature (°C): | 10 to 60 |
|---|
Power Input | 5V/2A |
|---|
Length (mm): | 50 |
|---|
Width (mm): | 20 |
|---|
Height (mm): | 05 |
|---|
Weight (g): | 05 |
|---|
Shipping Weight | 0.01 kg |
|---|
Shipping Dimensions | 8 × 6 × 2 cm |
|---|
